Convertidor de medios gigabit ethernet a fibra óptica, conector LC, multimodo (MMF), distancia de 220 hasta 500 m

Overview
The Allied Telesis MMC2000 Series of Gigabit mini media converters leverages its smaller size to not only help the environment with a small carbon footprint, but also to save space in its working environment. Despite its compact size, the MMC2000 Series delivers all the power and functionality of standard size media converters.

Extend Networks
The MMC2000 Series mini media converters are the ideal solution for upgrading a traditional 100Mbps Ethernet network or extending a Gigabit network. The MMC2000 Series is designed to extend the distance of a network by converting Gigabit data between twisted pair and fiber-optic cabling. The MMC2000 features a 1000X fiber port and a 10/100/1000T twisted-pair port. The fiber-optic port features an SC, ST, LC, or SFP connector (depending on the model). The twisted-pair port has an RJ-45 connector with a maximum operating distance of 100 meters (328 feet).

VLAN Support
Many new backbone switch products now support the industry-standard IEEE 802.1Q specification for Virtual LANs (VLANs) that send extra-long data packets on the network. The MMC2000 switches are fully compatible with these long packets, enabling them to be used in modern networks. Media converters not supporting this feature discard these extra long packets, making them unsuitable for modern networks.

Small and Flexible
The smaller size and external power supply of the MMC2000 Series allows them to be used almost anywhere.

Smart MissingLink (SML)
The Smart MissingLink™ (SML) feature monitors network connections and provides notification when network segments fail, allowing network managers to quickly identify the source and location of failed segments and minimize downtime.

Smart Link Restoration
Smart Link restoration allows the devices, in cases of power failure, link loss or other interrupted service, to automatically restore the link without the need to restart/reset them.

Power Saving
The MMC Series continues the Allied Telesis commitment to the environment with over 50% power savings. With just 1.7W of power usage, the MMC Series media converters are some of the most efficient in the market today.

Allied Telesis AT-MMC2000/LC-90. Rango máximo de transferencia de datos: 1000 Mbit/s, Interfaz de convertidor de entrada: 10Base-T, 100Base-T, 1000Base-T, Interfaz de convertidor de salida: 1000Base-SX. Conector fibra óptica: LC, Tecnología de conectividad: Alámbrico. Distancia de transferencia máxima: 500 m, Longitud de onda: 850 nm, Estructura de modo de fibra: Multimodo. Color del producto: Plata, Certificación: UL60950-1 EN60950-1 FCC Class A EN55022 Class A CISPR 22 Class A C-TICK VCCI. Voltaje de entrada: 12 V, Corriente de entrada: 0.14 A

Rango máximo de transferencia de datos	1000 Mbit/s
Interfaz de convertidor de entrada	10Base-T, 100Base-T, 1000Base-T
Interfaz de convertidor de salida	1000Base-SX
Estándares de red	IEEE 802.1Q
Tipo de interfaz ethernet	Gigabit Ethernet
Ethernet LAN, velocidad de transferencia de datos	10,100,1000 Mbit/s
Tecnología de fibra de cableado ethernet	1000BASE‑SX
Jumbo Frames, soporte	Si
Soporte VLAN	Si
Sistema de dúplex	Completo
Conector fibra óptica	LC
Tecnología de conectividad	Alámbrico
Ethernet LAN (RJ-45) cantidad de puertos	1
Puertos de canal de fibra	2
Distancia de transferencia máxima	500 m
Longitud de onda	850 nm
Estructura de modo de fibra	Multimodo
Interno	No
Color del producto	Plata
Certificación	UL60950-1 EN60950-1 FCC Class A EN55022 Class A CISPR 22 Class A C-TICK VCCI
Voltaje de entrada	12 V
Corriente de entrada	0.14 A
Ancho	56 mm
Profundidad	101,6 mm
Altura	21,8 mm
Peso	170 g
Intervalo de temperatura operativa	0 - 50 °C
Intervalo de temperatura de almacenaje	-30 - 70 °C
Intervalo de humedad relativa para funcionamiento	5 - 95%
Intervalo de humedad relativa durante almacenaje	5 - 95%
Altitud de funcionamiento	0 - 3048 m
